• QBridgeV2 device provides a low cost efficient way to connect your PC to I2C, SPI (4 wires) or CAN bus. Turn any PC into a CAN node, SPI or I2C master.

• No programming needed (in ASCII mode).

• Female DB 9 for Host PC connection and Female DB9 for external target connection.

• QBridge V2 supports both ASCII mode and Binary modes.

•  In ASCII mode, user can use Windows Hyper Terminal to access I2C, SPI or CAN bus in no time.  No programming needed!

• The Binary mode extends the flexibility for user to develop his own application.  QBridge V2 provides the protocol for user to access the QBridge via RS232 port.

• QBridgeV2 CAN (Controller Area Network)

• Programmable bit rate up to 1MBits.

• Configurable 6 acceptance filters and 2 masks

• Three transmit buffers

• Time stamp on received messages

• Four operations: Listen, Operation, Listen, loop back.

• QBridgeV2 I2C & SPI

• Supports 100K and 400K I2C speed.

• Supports SPI (4 wires) speed up to 10MBits.

• Flexible selection on SPI clock polarity.
